| General Specifications |
| Operating System | Android 4.4 OS |
| CPU | MSM8916,A53,4core CPU ,1.2GHz |
| RAM | RAM: 2G/FLASH: 16G |
| Extended Storage | Micro SD ,Maximum 32G |
| USB port | 5 pin MicroUSB, support OTG (U-disk/Mouse/keyboard/USBEthernet cable) |
| OTG | Support,through OTG can meet 100M network port , network card setup,PPPoE dial-up,web browsing ,Support OTG extend RS232 serial port |
| External port | Charge port ,headphone port |
| Protection Grade |
| Industrial Protection Grade | IP67 |
| Drop Grade | Drop resistance from 1.2m |
| Wireless Communication |
| Bluetooth | Support 4.0 |
| GPS | Support GPS ,DBS ,GLONASS and professional GPS,Ublox;GPS and Beidou(alternative) |
| WIFI | Support IEEE802.11b/g/n |
| 4G | FDD/WCDMA/GSM
LTE_FDD B1/B3/B7 LTE_TDD B41/B40
WCDMA B1/B2/B5
GSM 900/1800/1900 |
| Data Acquisition(Optional) |
| Fingerprint Identification | Support fingerprint data acquisition,fingerprint resolution 150x200 |
| Far infrared meter reading | woring frequency 37.9K |
| RFID |
| LF RFID | 134KHZ LF RFID or 124KHZ LF RFID |
| NFC(HF) RFID | Working frequency : 13.56 MHZ
Profile: Support ISO/IEC 15693,ISO/IEC 14443A profile
Support Cards :SR176,SRIX4K(TYPE-B),I-Code2,TI RFID label-it
HF1,EM4034 ,Mifare Classic ETC
Identification distance :not more than 5cm |
| UHF RFID | Working frequency : 840-960MHZ
Support agreement :EPC C1 GEN2/ISO 18000-6C
Output power : 10dBm-30dBm
Identification distance : not more than 6 m |
| Physical Parmeters |
| Display Screen | 7 inch LCD screen ,1280x800 IPS screen ,capacitive touch screen |
| Keyboard | Android menu ,Homepage ,Returm,Volume,Barcode,ON/OFF ,Reset |
| Camera | 2 million pixels front camera ,8 million pixels rear camera with automatic focus and lighting function |
| Headset | 3.5mm audio interface,has mike and telephone receiver |
| LED indicatoe light | Support (ordinary ficker,Call fast flicker ,missed calls ) three status bar |
| Flashlight Function | Support ,can be used for emergency lighting |
| Googleplay store | Support |
| Gravity sensor | Support |
| Compass | Support |
| Vibrating motor | Support |
| FM | Support |
| Rechargeable Lithium Battery | 3.7V,7000mAh |
| Standby | Standby current less than 10mA |
| Dimension | 209mmx139mmx19mm |
| Weight | 590g |
| Environmental Characteristics |
| Working Temperature | -20 + 50 |
| Storge Temperature | -40 +60 |
| Humidity | 5% --95% relative humidity ;no condensation |
